The battery active equalizer (JK-B10A24S) is a balanced management system tailored for large-capacity series lithium battery packs.

Main Specifications

◆ Support 2-24 strings of battery packs;

◆ Real-time, active, energy transfer equalization, after reaching equilibrium, the voltage difference between single cells is ≤ 3mV; Lithium, lead-acid, super capacitor and other battery types;

◆ Independent setting within the range of 10A equalizing current, independent of single battery voltage difference;

◆ Support equalizing cascade, suitable for more than 24 series battery packs, theoretically infinite cascade ;

◆ Bluetooth communication function, equipped with APP, real-time viewing of battery status;

◆ Balanced line resistance detection, early detection of abnormal poor contact;

◆ Collection line and balance are independent to avoid the impact of large balance current on collection during balance;

◆ Power supply range: 40V ~100V;

◆ Low voltage shutdown function to prevent battery damage.

 Environmental conditions of use

a) Operating temperature range: -20℃～70℃;

b) Power requirements: 40~100V, can use battery self-powered or external power supply.

c) Power consumption: balanced state 10mA@100V, unbalanced state 6mA@100V.
